Koshin SEH Series

Features

This Japanese made Koshin SEH-25L 1” Ultralite pump powered by Honda GX25 four stroke petrol engine is capable of producing flows up to 115 L/min and a maximum head of 32 m (45 PSI). Designed for pumping clean water the Koshin 1” Ultralite is easy to move from job to job due to its 7 kg Ultralite design. This pump is suitable for a wide variety of applications including water transfer, mop up fire fighting, irrigation, campsites and high pressure spraying.

• Environment friendly low noise Honda engine produces half the noise compared to two-stroke engine.
• Made in Japan
• Light weight with built in handle and skids with rubber feet

Specifications

• Net weight: 5.5 kg
• Gross weight: 7 kg
• Liquid Consistency: Clear Water
• Product dimensions: L 375 mm x W 243 mm x H 320 mm

Pump

• Suction: 1″ Male BSP
• Discharge: 1″ Male BSP
• Max Flow 115 L/min
• Max Head: 32 m
• Max. suction depth: 8 m
• Material: Cast alloy pump body with cast iron impeller and volute
• Seals: NBR
• Maximum particle size: 1 mm

Engine

• Start: Recoil
• Type: Forced Air-Cooling 4-Stroke Gasoline Engine
• Model: Honda GX25
• Max. output: 0.72 kW / 7,000 RPM
• Fuel tank capacity: 0.53 L
• Engine oil capacity: 0.08 L
• Continuous operating time: 1 hr.

Accessories

• 3 Hose bands, 2 Hose couplings, 1 Strainer, 1 Engine tool sets

Applications

• Water Transfer
• Irrigation – Spraying
